Super Anchor Safety RLT Loop Top Field Weld Risers - 12", 18"

The 1044-WG and 1045-WG are hot-dip galvanized steel loop-top risers designed to be field welded to structure, providing a permanent anchor point for single-user fall protection. The 1044-WG has a 12-inch riser height, while the 1045-WG is 18-inch, both with 3.0-inch outer diameter risers. Each riser meets minimum base tensile strength of 5,000 lb and loop-top tensile rating of 10,000 lb, and is suitable for window washing, PPE tie-off, and horizontal lifeline use.

Features

• Weld-on loop-top riser anchors for permanent installation
• 5,000 lb minimum base tensile strength
• 10,000 lb loop-top tensile rating
• Hot-dip galvanized steel construction
• Available in 12" (1044-WG) and 18" (1045-WG) heights

• Device: permanent loop-top tie-back / PPE anchor riser for field welding to structural steel
• Intended use: single-user fall arrest; 360-degree use for restraint; multi-user/HLL only as part of an engineered system
• Structure attachment: field weld to structural steel per engineer-of-record and qualified welder procedure (WPS)
• Material: A36 carbon steel or 316 stainless steel
• Finish options: hot-dip galvanized (ASTM A123) or stainless (passivated)
• Connector loop: 2.0 in inside-diameter loop-top (smooth radius for hooks/carabiners)
• Base plate (typical): 6 in × 6 in × 3/8 in weld plate (project details may specify 8 in × 8 in × 1/2 in)
• Strength rating: minimum 5,000 lb in any direction of applied load
• Design load: 1,250 lb working design load (4:1 safety factor)
• Proof load (W-suffix models): up to 2,500 lb during certification
• Temperature range: −30 °F to 130 °F
• Compliance (when installed and used as directed): OSHA 1926.502 / 1910.140; ANSI Z359.1 / A10.32; IWCA I-14.1; Cal-OSHA §3291 (where applicable)
• Use limitations: personal fall protection only—do not use for hoisting or as structural bracing

Per-size details

• 12" riser
  • Riser height: 12 in to loop centerline (≈12.4–12.8 in overall including plate)
  • Dimensions (assembled footprint): plate 6 × 6 × 3/8 in; loop I.D. 2.0 in
  • Weight: approximately 6.5–7.8 lb (finish and hardware tagging can vary)
• 18" riser
  • Riser height: 18 in to loop centerline (≈18.4–18.8 in overall including plate)
  • Dimensions (assembled footprint): plate 6 × 6 × 3/8 in; loop I.D. 2.0 in
  • Weight: approximately 8.8–10.5 lb

Installation notes (summary)

• Weld all around per WPS using matching fillers; maintain edge distances/clearances; protect finishes; proof-load/test where required; label/ID for inspection and recertification.

• Select the riser height (12" for 1044-WG or 18" for 1045-WG) appropriate for structure and clearance needs.
• Position the riser, aligning the base to the structural member where it will be welded.
• Field-weld the riser per manufacturer’s welding procedure specifications.
• Allow the weld to cool, then inspect weld integrity and alignment.
• Install any loop-top attachments, and verify tensile performance via proof load or inspection prior to use.

Q: What is the difference between 1044-WG and 1045-WG?
A: 1044-WG is a 12" riser; 1045-WG is an 18" riser version of the weld-on loop-top riser.

Q: What is the tensile strength of the base and loop top?
A: Base minimum tensile is 5,000 lb; the loop-top is rated to 10,000 lb.

Q: What material and finish are these risers made of?
A: Q235 steel with hot-dip galvanized coating.

Q: What standards do these risers comply with?
A: They comply with ANSI Z359.18, OSHA 1926.502, and IWCA I-14.1 for window washing.

Q: What is the weight of each riser?
A: 1044-WG weighs approximately 6.9 lb; 1045-WG weighs approximately 10.4 lb.
