Price: $21.50
Item #SAS-2813
Write a review!
Quantity:
Description
This is a single sided D-ring anchorage device that are installed at the ridge, hip-ridge or in the field for permanent or temporary use. Permanent use anchors are supplied with stainless steel nail fasteners and a butyl strip flashing. The 8-1/2” length is idea for shingle type roofs allowing the anchor to be attached over the roofing material. The RS-10 is exactly ½ of our RetroFit anchor, making it an ideal complimentary anchor for hip ridges and shed roofs.
Available with a “Dual Hole” option to accept larger diameter fasteners to give you more mounting options. We can supply you with special, high strength Head-Lok Fasteners up to 12” long for deeper substrate installation.
- Built for Shingle Roofing and Wall Applications
- Permanent Low-Profile Design Does Not Detract from Roof
- Use on Roof or Wall Surfaces
- Easy to Install and Includes all Fasteners
- Rated for 5,000 OSHA Fall Arrest
For Asphalt Shingle, Wood, Copper, Slate, Metal and "Simulated Tile" Metal Roofs
Please read and understand the manufacturer instructions before using this product
Specifications
- Device - Single D-ring Permanent Roof Anchor
- Fall Protection Rating - Fall Arrest and Fall Restraint
- Structure Attachment (Wood) - Wood Framed Structure
- Structure Attachment (Steel) - 24 gauge minimum metal decking with SAS engineering
- Minimum Breaking - 5,000 pounds
- Minimum Tensile - 5,000 pounds
- Material (Strapping) - 20 gauge 430 Stainless Steel
- Material (D-rings) - Stamped Dacromet or yellow zinc plated steel
- Stamp Marks - Date of Manufacture Year/Month
- Flashing - Butyl flashing for waterproofing 2 @ 4"
- Maximum User Weight - 340 pounds including tools and equipment
- Hardware - 3-1/4" Stainless steel nails
- OSHA Standard - 1926:502 and 1910.66
- ANSI Standard - Z359.1-07 and A10.32-2012
- Canadian 3rd Party - Certified by L'Ordre des Ingenierus du Quebec
