Super Anchor Safety - TB3-6072 - 3 D-Ring Fall Arrester Harness, Tongue Buckle

The TB3-6072 series is a full-body, 3 D-ring fall arrester harness built for both fall arrest and restraint use. It features a padded waistbelt, breathable mesh frame, hi-viz polyester webbing, and tongue buckle leg straps with quick-connect chest buckle. Offered in sizes from small to 2X, it supports up to 310 lb (for sizes S–XL) and up to 400 lb for size 2X.

Features

• 3 D-ring configuration: 1 dorsal and 2 side rings for positioning
• Hi-visibility polyester webbing with padded frame and waistbelt
• Tongue buckle leg straps and quick-connect chest buckle
• Lanyard park/tool holder features integrated
• Dual fall indictor labels for safety inspection

• Device: full-body fall-arrest harness with 3 D-rings (rear dorsal + two hip D-rings for positioning/restraint)
• Model: TB3-6072 — 3 D-Ring Fall Arrester Harness, Tongue-Buckle leg straps
• Intended Use: fall arrest (rear D-ring) and work positioning/restraint (side D-rings) as part of a compliant PFAS
• Materials (Webbing): 1-3/4 in high-tenacity polyester, abrasion/UV resistant
• Materials (Hardware): forged steel D-rings and tongue buckles, zinc-plated corrosion-resistant finish
• Stitching: high-strength bar-tack with contrasting inspection thread; load paths sewn for ≥5,000 lb system strength
• Adjustment Points: shoulders, chest, and legs; web-keepers for excess strap management
• Leg Buckles: tongue-buckle style for positive hole engagement and easy donning with gloves
• Chest Buckle: pass-through/mating buckle (typical)
• D-Ring Size: approx. 2.0 in inside diameter; smooth radius for snap hooks/carabiners
• Web Width: 1.75 in (44 mm) primary straps
• Dimensions / Fit Range: adjustable to common sizes — chest ~36–54 in; waist ~32–50 in; thigh ~22–36 in (size dependent)
• Weight (Harness Only): ~4.4–5.8 lb depending on size/options
• Maximum User Capacity: 310 lb including tools and equipment (per ANSI Z359.11)
• Minimum Tensile (Webbing): ≥6,000 lb
• Attachment / D-Ring Strength: ≥5,000 lb
• Hardware / Gate Strength: ≥3,600 lb
• Comfort / Features: sub-pelvic strap, lanyard keepers, impact/inspection indicator labels, serialized ID tag
• Operating Temperature: approximately −30 °F to 120 °F (typical jobsite conditions)
• Compliance: OSHA 1910.140 / 1926.502; ANSI Z359.11 (revision current at manufacture)
• Inspection / Retirement: pre-use and periodic competent-person inspections; remove from service after any arrest or if stitching damage, deformation, corrosion, cuts, UV embrittlement, or illegible labels are found

• Select the correct size (HS through 2X) based on body dimensions and weight.
• Put on the harness by slipping arms into the shoulder straps and pulling the backpad into position.
• Buckle the quick-connect chest strap and tongue buckle leg straps; adjust for snug fit.
• Position the dorsal D-ring 6-12 inches below shoulder level, and use side D-rings for work positioning.
• Connect your lanyard or SRL to the dorsal D-ring and inspect all webbing, hardware, and indicators before use.

Q: What is the maximum weight capacity?
A: Up to 310 lb (sizes HS to HX), and up to 400 lb for size 2X.

Q: How many D-rings does the harness have?
A: Three — one dorsal (rear) and two side D-rings.

Q: What is the material strength of the D-rings?
A: Drop-forged steel, minimum tensile 5,000 lb, proof loaded to 3,600 lb.

Q: What webbing strength is used?
A: 1-3/4" polyester webbing with 6,000 lb minimum breaking strength.

Q: What safety standards does this harness comply with?
A: ANSI Z359.11-21, OSHA 1926.502, CSA Z259.10 (Class A/P).
