- Engineered for permanent installation on wood roof truss members (2 x 4 or larger), providing a dependable long-term tie-off point for maintenance and repairs
- Manufactured from premium 304 stainless steel to ensure maximum durability and superior corrosion resistance in all weather conditions
- Features a low-profile, fixed D-ring connection point that stays accessible for secure attachment of lanyards and other fall-protection components
- Offers flexible installation options, allowing the anchor to be mounted to the truss structure either before or after roof sheathing is applied
- Includes all necessary 1-1/2 inch stainless steel fasteners to guarantee a secure, high-strength bond to the wood substrate
- Designed for ongoing safety with a minimum tensile strength of 3,600 lbs, meeting the requirements for personal fall-arrest systems
Price: $44.75
Item #FALLTECH-7429SS
Write a review!
Description
This anchor is intended for permanent installation on wood truss structures to provide a secure attachment point for fall-protection systems. It features a stainless-steel construction designed for long-term use and includes a fixed D-ring connection point. The anchor installs directly onto the truss and provides a reliable tie-off location for personal fall-arrest equipment.
Key features:
-
Designed for permanent installation on wood truss structures
-
Stainless-steel body for long-term durability
-
Fixed D-ring connection point for fall-protection components
-
Provides a dedicated tie-off point for ongoing fall-arrest use
Specifications
- Installs on roof truss members 2 x 4 or larger
- Available as an anchor only or as a kit including weather flashing and cap
- Durable Stainless steel construction for long life
- May be installed before or after installation of roof sheathing
- All fasteners included
- Anchor - 304 Stainless steel
- Fasteners - 1-1/2" Stainless steel
- Flange - EPDM
- Tensile Strength - Min. 3,600 lbs.
- Max. Capacity - 310 lbs.
FAQs
Q: Where on the truss should this anchor be installed?
A: It should be mounted on a structurally sound wood truss member at a location that provides a stable and accessible tie-off point.
Q: Can this anchor be used on metal trusses?
A: No — this model is designed for wood truss structures only.
Q: What type of inspection should be performed after installation?
A: Check that fasteners remain tight, the stainless steel body shows no deformation or corrosion, and that the D-ring moves freely without obstruction.
Q: Can this anchor remain in place after construction is complete?
A: Yes — it is designed as a permanent anchor and may remain installed for future tie-off needs.
