- Features a double-leg "Y" configuration that enables 100% tie-off, allowing workers to remain safely connected while transitioning between structural anchor points
- Engineered with integrated tie-back D-rings on each leg, allowing the lanyard to be wrapped directly around structural members and eliminating the need for separate anchor straps
- Constructed with premium jacketed double-layer polyester webbing, specifically designed to provide superior abrasion resistance and long-term durability in abrasive environments
- Includes the patented ViewPack® energy absorber cover with a clear inspection window and WrapPack label protection for rapid and reliable pre-use safety checks
- Equipped with high-strength plated alloy steel snap hooks featuring 5,000 lb static strength and 3,600 lb gate strength for secure harness and anchorage connections
- Designed to limit average arrest forces to 900 lbs and maximum arrest forces to 1,800 lbs with a maximum arrest distance of 48 inches
- Fully compliant with ANSI Z359.13-2013 and OSHA 1926.502/1910.66 regulations, supporting a user capacity of 130 to 310 lbs
Price: $109.00
Item #FALLTECH-826082D
Write a review!
Description
This lanyard is engineered with a double-leg configuration to support 100 % tie-off during movement and repositioning. It is built with jacketed double-layer polyester webbing to provide added strength and abrasion resistance. The ViewPack® energy absorber is covered with an inspection window and includes WrapPack label protection for easier servicing. Tie-back D-rings remove the need for a separate anchor point by enabling wrap-around anchorage, and alloy steel snap hooks attach to the harness and anchor for reliable connection.
Key features:
-
Jacketed double-layer polyester webbing for added strength and abrasion resistance
-
Tie-back D-rings for wrap-around anchorage, eliminating the need for a separate anchor point
-
ViewPack® energy absorber cover with inspection window and WrapPack label protection
-
Double-leg design with steel snap hooks for 100 % tie-off
Specifications
- SKU: 826082D
-
Product type: ViewPack® Tie-Back Energy Absorbing Lanyard, Double-Leg
-
Length: 6 ft
-
Webbing material: jacketed double-layer polyester webbing
-
Connectors: plated alloy steel snap hooks; minimum static strength 5,000 lb; gate strength 3,600 lb
-
D-rings: plated alloy steel tie-back D-rings; minimum static strength 5,000 lb
-
Static strength: minimum 5,000 lb
-
ANSI Lanyard Class: 6 ft free fall
-
Max arrest distance: 48″
-
Average arrest force: 900 lb
-
Max arrest force: 1,800 lb
-
ANSI user capacity: 130 to 310 lb max
-
OSHA user capacity: 130 to 310 lb max
-
Compliance: meets ANSI Z359.13-2013 and OSHA 1926.502 / 1910.66
FAQs
Q: What does the “tie-back” feature mean for this lanyard?
A: The tie-back means the D-rings allow direct wrap-around of structural members so you do not need a separate fixed anchor point.
Q: How can I inspect the energy absorber without removing it?
A: Use the ViewPack® cover that includes an inspection window so you can visually check the absorber’s condition.
Q: Can I stay connected at all times when repositioning with this lanyard?
A: Yes — the double-leg (Y-leg) design supports 100 % tie-off, allowing one leg to remain connected while the other is moved.
Q: What webbing construction enhances durability in this model?
A: It uses jacketed double-layer polyester webbing to provide extra abrasion resistance for demanding work environments.
