What's New?
- S-5 has enhanced their flagship snow guard system with customer-inspired design upgrades to make installation faster and simpler.
- An innovative internal splice has eliminated the need for preassembly and in-field cutting. The VersaClip™ can now be installed directly over all splices – drastically reducing your time on the roof.
- The result? A true lay-and-play system engineered for both standing seam and exposed-fastened roof profiles.
Description
The S-5! ColorGard 2.0 snow retention system provides engineered solutions for standing seam and exposed-fastened metal roofs. Its modular design includes unpunched and punched 7' 8" crossmembers with internal splices, SnoClip II-2.0 and SnoClip III-2.0 for seam-specific applications, and VersaClip-2.0 for attaching unpunched rails. All components work together to deliver long-term, aesthetically matched snow retention using a 2" ColorStrip.
Key Features:
• Engineered snow guard system for metal roofs
• ColorGard 2.0 crossmembers available in unpunched and punched versions
• SnoClip II-2.0 and III-2.0 reduce ice migration for taller seams
• VersaClip-2.0 enables flexible attachment of unpunched bars
• Accepts 2" ColorStrip for color-matched integration with roof panels
Specifications
• Crossmember length: 7' 8" standard sections with internal splice included
• ColorStrip: 2" strip sourced from panel manufacturer; fits into bar slot
• SnoClip II-2.0: for seam heights 1" to 1-3/4"
• SnoClip III-2.0: for seam heights 2" to 3-1/4""
• VersaClip-2.0: required at each clamp/bracket connection when using unpunched crossmembers
• Material: Aluminum bars with stainless hardware and compatible accessories
• Includes: All individual components packaged per product listing
How To
- Determine snow retention layout and calculate bar placement per engineering guidelines.
-
Install S-5! clamps or brackets along seams or panel ribs.
-
For unpunched crossmembers, slide VersaClip-2.0 onto the bar at each connection point.
-
Position crossmembers with included splices, then fasten using M8 hardware.
-
Insert ColorStrip into crossmember slot for color match.
-
Add SnoClip II-2.0 or SnoClip III-2.0 as required to reduce ice migration at seam bases.
FAQs
Q: What is the difference between punched and unpunched crossmembers?
A: Punched bars are pre-slotted every 4", while unpunched require VersaClip-2.0 for flexible seam spacing.
Q: Do crossmembers include splices?
A: Yes. Each ColorGard 2.0 crossmember includes one internal splice for structural continuity.
Q: When should I use SnoClip II-2.0 vs. SnoClip III-2.0?
A: Use SnoClip II-2.0 for seams 1"–1-3/4"; use SnoClip III-2.0 for seams 2"–3-1/4".
Q: What role does the ColorStrip play?
A: The ColorStrip provides long-term color matching and is inserted into the crossmember slot.
Q: Is VersaClip-2.0 required for both crossmember types?
A: No. VersaClip-2.0 is only used with unpunched crossmembers; punched bars do not require clips.
