JL Industries TM-1218CW 12 × 18 Fire-Rated Uninsulated Access Panel – 1½-Hour Ceiling, White Powder Coat

The JL Industries TM-1218CW Fire Extinguisher Cabinet is a durable and practical housing solution for extinguishers in wall assemblies. Made from cold-rolled steel with tubular steel trim, it offers both strength and architectural appeal. The clear acrylic glazing panel ensures visibility of the extinguisher while protecting it from damage. Finished in a white powder coat, the TM-1218CW is designed for recessed installation and is well-suited for commercial, institutional, and residential projects.

Key Features

• Tubular steel trim for a clean, flush look
• Cold-rolled steel body with durable powder coat finish
• Clear acrylic glazing provides extinguisher visibility
• Sized at 12″ × 18″ for medium extinguishers
• Simple recessed installation design
• Made in the USA

Model: TM-1218CW (12″ × 18″)

Manufacturer: JL Industries / Activar Construction Products Group

Application: Wall (vertical assemblies)

Construction: Cold-rolled steel cabinet with tubular trim

Door: Cold-rolled steel with clear acrylic glazing

Hinge & Closure: Continuous hinge with latch mechanism

Trim Style: Tubular steel trim, flush mounting

Finish: White powder coat; additional finishes available

Opening Size: Door – 12″ H × 18″ W; Opening – approx. 12 3/8″ × 18 3/8″; Overall – approx. 14″ × 20″ × 2½″

Glazing: Clear acrylic window

Made In: USA

Weight: Approx. 11 lb

• Confirm wall space for the 12″ × 18″ cabinet.
• Cut the wall opening according to manufacturer’s recommended dimensions.
• Insert the cabinet body into the opening, aligning the flange flush with the wall.
• Secure the frame with appropriate fasteners.
• Place the extinguisher inside the cabinet body.
• Close and latch the door, verifying clear visibility of the extinguisher.

Q: What extinguisher size fits in the TM-1218CW?
A: It is designed to accommodate extinguishers up to approximately 10 lb.

Q: What does CW mean in the model number?
A: CW indicates clear window glazing with tubular trim.

Q: Is this cabinet fire-rated?
A: No, the TM series is not fire-rated.

Q: What type of glazing is used?
A: The glazing is clear acrylic.

Q: Can the TM-1218CW be surface-mounted?
A: No, it is designed exclusively for recessed installation.
