- Features a specialized double D-ring design that provides convenient tie-off access from both sides of the roof ridge for improved worker mobility
- Engineered with an integrated butyl sealing strip that creates a watertight barrier upon installation to prevent leaks and protect the roof structure
- Constructed from high-quality stainless and zinc-plated steel to offer superior corrosion resistance and long-term durability in all weather conditions
- Designed with a low-profile aesthetic that allows the anchor body to be installed seamlessly under shingles, preserving the home's curb appeal
- Includes 8 stainless steel spiral nails required for a secure and permanent installation directly into the wood roof framing
Price: $27.78
Item #GUA-00510
Write a review!
Description
The Guardian Ridge-It Permanent Roof Anchor (00510) is a durable and discreet anchorage solution designed for residential roofs. Featuring double D-rings spaced across an 18-inch stainless and zinc-plated steel body with a butyl sealing strip for watertight installation, this permanent anchor installs under roofing shingles for a low-profile appearance. Supporting one personal fall arrest system with a minimum breaking strength of 5,000 lb, it offers safety without compromising roof aesthetics. Lightweight and easy to install, it delivers reliable, code-compliant fall protection.
Key Features:
-
Double D-ring design offers tie-off access on both sides of the roof ridge
-
Durable stainless and zinc-plated steel construction
-
Butyl sealing strip ensures a watertight, permanent installation
-
Low-profile design blends under shingles seamlessly
-
Lightweight and easy to install
-
Supports one personal fall arrest system (OSHA/ANSI compliant)
Specifications
- Model: 00510
-
Type: Permanent Roof Anchor (Ridge-It Double D-Ring)
-
Material: Stainless steel, zinc-plated steel, butyl
-
Weight: ~1.1 lb
- hnmLength: 18 in
-
Includes: 8 stainless steel spiral nails for installation
-
Worker Capacity: 130–420 lb (including tools and clothing)
-
Minimum Breaking Strength: 5,000 lb
-
Usage: For single-user fall arrest; restraint systems permitted (no free fall)
-
Reuse: Not reusable after installation
How To
- Position the anchor centered along the roof ridge, ensuring it lies flat under shingles.
-
Press the butyl sealing strip onto the roof surface to ensure proper sealing.
-
Secure the anchor with the 8 provided stainless spiral nails.
-
Attach one personal fall arrest system to one of the D-rings (no free fall permitted).
-
Inspect the anchor before each use. Do not reuse once installed.
FAQs
Q: How many D-rings does this model have?
A: It includes two D-rings, offering tie-off points on both sides of the ridge.
Q: What is the weight capacity?
A: It supports a single user weighing up to 420 lb (including tools).
Q: What is its minimum breaking strength?
A: Rated at 5,000 lb.
Q: Is this anchor reusable?
A: No—it's designed for permanent installation and not to be reused.
Q: Does it support restraint applications?
A: Yes—restraint is permitted with no free fall, under applicable system conditions.
