S-5 Gripper Strut GF-26

The S-5! Gripper Strut GF-26 is the primary rail component in the GRIPPERFIX utility mounting system for metal roofs. Manufactured from prime Series 6000 aluminum, it is available in 26-inch length (also sold in 52-inch as GF-52). The GF-26 works with CF Tabs for standing seam clamps or EF Tabs for exposed fastener panels. It accepts hardware such as M8-1.5×16 mm hex bolts and M8 flange nuts (sold separately) for securing tabs and attachments.

Key Features:

• Prime Series 6000 aluminum construction, corrosion resistant
• Available in 26-inch (GF-26) length; 52-inch (GF-52) also in same series
• Compatible with CF Tab or EF Tab components
• Accepts M8-1.5×16 mm hex bolts and M8 flange nuts for attachments
• Designed for mounting utilities using GRIPPERFIX system

• Material: Series 6000 aluminum alloy
• Length: 26-inch (66 cm approx) for GF-26 version
• Compatible tabs: CF Tab, EF Tab
• Hardware required: M8-1.5×16 mm hex bolts, M8 flange nuts (sold separately)
• Includes: One Gripper Strut GF-26 unit

• Select the GF-26 Gripper Strut and locate position on roof for mounting.
• Choose CF Tab for standing seam or EF Tab for exposed fastener panel application.
• Slide the chosen Tabs into the channel of the GF-26 strut.
• Align Tabs over clamp or roof panel where the Strut will be attached.
• Secure Tabs using M8-1.5×16 mm hex bolts and matching M8 flange nuts.
• Attach utilities or equipment to the strut using inserted hardware; verify secure and aligned installation.

Q: What material is the GF-26 Gripper Strut made from?
A: Prime Series 6000 aluminum alloy.

Q: What tabs can be used with GF-26?
A: CF Tabs (for standing seam clamps) or EF Tabs (for exposed fastener panels).

Q: What hardware is needed to install GF-26 with tabs?
A: M8-1.5×16 mm hex bolts and M8 flange nuts (tabs and hardware are sold separately in many cases).

Q: Are there other length options besides 26-inch?
A: Yes; the same strut is available in 52-inch length (GF-52).
