Price: $415.00
Item #POR-32131
Write a review!
Description
The Portals Plus Large RC-2A Straight Sided Curb (20″ × 20″ × 11″ High) is designed for roof decks with lightweight fill or tapered insulation. Fabricated from 18-gauge galvanized steel, it includes an integral base plate, continuously welded corner seams, and a factory-installed wood nailer. The curb also contains 1.5″ thick, 3 lb/ft³ rigid fiberglass insulation on all four sides, providing thermal protection and structural strength for pipe portal and rooftop equipment systems.
Key features:
-
Fabricated from 18-gauge galvanized steel with continuously welded seams and integral base plate.
-
Factory-installed wood nailer for secure flashing and attachment.
-
1.5″ rigid fiberglass insulation (3 lb/ft³) on all four sides for condensation control.
-
Measures 20″ × 20″ × 11″ high — designed for decks with lightweight fill or tapered insulation.
Specifications
- SKU: 38131 (POR-38131)
-
Product type: Large RC-2A Straight Sided Roof Curb
-
Length: 20″
-
Width: 20″
-
Height: 11″
-
Material: 18-gauge galvanized steel
-
Insulation: 1.5″ rigid fiberglass (3 lb/ft³ density)
-
Construction: Continuously welded corner seams with integral base plate and factory wood nailer
-
Application: For roof decks with lightweight fill or tapered insulation
FAQs
Q: What roof deck conditions is this curb intended for?
A: It is designed for decks with lightweight fill or tapered insulation where a straight-sided curb is required.
Q: What are the dimensions of this curb?
A: This curb measures 20″ in length, 20″ in width, and 11″ in height.
Q: Does this curb include any pipe portal covers or caps?
A: No — this item is the structural curb only. Covers and caps are sold separately as part of Portals Plus Pipe Portal systems.
Q: Why is rigid fiberglass insulation used in the curb?
A: It helps prevent condensation and provides thermal protection for rooftop installations.
