**The 24", 36", and 48" are prone to an extended lead time**
**Free freight charges do not apply**
Price: $99.55
Item #CPORT-CXW-12
Write a review!
Description
The C-Port CXW12 widebody rubber support is engineered for heavier weight conduit, piping and other heavy duty rooftop applications. The base is made of 100% recycled rubber and is suitable for non-penetrating use on flat surfaces or roofing materials. The wide 12" base supports heavier loads while providing stable placement and durability.
Key features:
-
100% recycled rubber base with UV resistance
-
Widebody 12" width designed for heavy duty conduit and piping
-
Non-penetrating installation on flat surfaces or roofing materials
-
Accepts screw fasteners to secure one or two-hole straps or clamps
Specifications
- Base: 100% recycled rubber, UV resistant
-
Warranty: 10 years
- May qualify for L.E.E.D credits.
C-Port CXW Series Specifications
| SKU |
Height |
Width |
Length |
Weight |
Max Load |
| CXW12 |
2 1/2” (64mm) |
12” (305mm) |
12” (305mm) |
9.56 lbs |
1200 lbs |
| CXW24 |
2 1/2” (64mm) |
12” (305mm) |
24” (610mm) |
19.12 lbs |
2400 lbs |
| CXW36 |
2 1/2” (64mm) |
12” (305mm) |
36” (914mm) |
28.66 lbs |
3600 lbs |
| CXW48 |
2 1/2” (64mm) |
12” (305mm) |
48” (1219mm) |
38.22 lbs |
4800 lbs |
FAQs
Q: Can CXW supports be used on all roofing materials?
A: Yes, they can be used on any roofing surface or other flat substrate.
Q: Do CXW supports include clamps or fasteners?
A: No, clamps and fasteners must be purchased separately.
Q: What is the difference between CXW and standard C-Port supports?
A: The CXW models have a wider base for heavier applications and improved load distribution.
Q: Are longer CXW models interchangeable in installation use?
A: Yes, longer lengths like 24", 36", and 48" provide additional stability and surface coverage.
