- Features a double-leg "Y" configuration that enables 100% tie-off, allowing users to remain continuously protected while transitioning between anchor points
- Utilizes a low-profile internal full-length energy absorber housed within tubular webbing, eliminating the need for a bulky external shock pack
- Engineered with a contrasting load-indicator stitch that provides an immediate visual signal if the lanyard has been deployed in a fall event
- Constructed from high-tenacity tubular polyester webbing for superior resistance against abrasion and UV degradation in harsh environments
- Equipped with heavy-duty plated alloy steel snap hooks on all ends, featuring a 5,000 lb minimum static strength and 3,600 lb gate strength
- Designed to limit average arrest forces to 900 lbs and maximum arrest forces to 1,800 lbs, with a maximum arrest distance of 48 inches
- Fully compliant with ANSI Z359.13-2013 regulations, supporting a standard user capacity of 130 to 310 lbs
Price: $72.80
Item #FALLTECH-8259Y
Write a review!
Description
This double-leg internal energy absorbing lanyard features a low-profile tubular polyester webbing construction and includes a full-length internal energy absorber with a visual load-indicator stitch to show fall-event deployment. It is equipped with steel snap hooks at both legs for harness and anchorage connection, and the double-leg design supports 100% tie-off capability. The 6-foot length is suitable for many fall-protection applications where two-point connection is required.
Key features:
-
Tubular polyester webbing for abrasion and UV resistance
-
Full-length internal energy absorber with visual load-indicator stitching
-
Steel snap hooks for both harness and anchorage connections
-
Double-leg design facilitating 100% tie-off
Specifications
- SKU: 8259Y
-
Webbing: polyester; 5,000 lb minimum static strength
-
Energy absorber: full-length internal, with visual load-indicator stitch
-
Connectors: plated alloy steel; 5,000 lb minimum static strength with 3,600 lb gate strength
-
Static strength: 5,000 lb minimum
-
ANSI lanyard class: 6′ free fall
-
Maximum arrest distance: 48″
-
Average arrest force: 900 lb
-
Maximum arrest force: 1,800 lb
-
ANSI user capacity: 130 to 310 lb max
-
OSHA user capacity: 130 to 310 lb max
-
Compliance: ANSI Z359.13-2013
FAQs
Q: Why choose a double-leg lanyard like this one instead of a single-leg version?
A: A double-leg lanyard enables 100 % tie-off, meaning the user can remain connected while repositioning or moving between anchor points without disconnecting.
Q: What does the visual load-indicator stitch help with?
A: It provides a visual cue showing whether the energy absorber has been deployed in a fall event, which is vital for determining serviceability.
Q: How should the tubular webbing be inspected before use?
A: Inspect the webbing for cuts, UV damage, fraying, or damage to the load-indicator stitch; ensure the webbing remains clean and functional.
Q: What specific checks are needed for the steel snap hooks?
A: Before each use verify that each snap hook gate opens and closes properly, locks when released, shows no deformation or corrosion, and that the snap hook rating remains legible.
