- Specifically engineered for leading-edge applications and scenarios where anchorage is located at foot-level or up to 5 feet below the user’s dorsal D-ring
- Features a high-strength 7/32-inch galvanized steel cable for superior cut and abrasion resistance when the lifeline travels over sharp or exposed edges
- Constructed with a rugged powder-coated aluminum housing featuring a side-payout design and integrated handle for enhanced durability and easier transport
- Includes an external ViewPack® energy absorber cover that provides controlled deceleration and allows for quick visual inspection of the shock pack's condition
- Equipped with a load-indicating swivel snap hook that provides a clear visual signal if a fall event has occurred and the unit requires service
- Classified as an ANSI Z359.14-2021 Class 2 SRL, delivering optimized braking performance for the most demanding industrial tie-off scenarios
- Fully compliant with OSHA 1926.502 and 1910.66 regulations, supporting a standard user capacity of 130 to 310 lbs
Price: $802.40
Item #FALLTECH-7232CLE
Write a review!
Description
This self-retracting lifeline is built for demanding leading-edge applications. It features a 7/32″ galvanized steel cable lifeline and an aluminum housing. The unit includes a load-indicating swivel snap hook, an internal inertial braking system, and an external ViewPack® energy absorber cover. It supports overhead or foot-level tie-off with Class 2 performance for enhanced safety when the lifeline may pass over exposed edges.
Key features:
-
7/32″ galvanized steel cable lifeline for increased cut-resistance
-
Load-indicating swivel snap hook to signal fall event deployment
-
External ViewPack® energy absorber cover enhances braking and protects cable integrity
-
Aluminum housing with side-payout design and built-in handle for easier use
Specifications
- SKU: 7232CLE
-
Cable: 7/32″ galvanized steel; minimum 3,600 lb static strength
-
Energy absorber: polyester tear-away
-
Lifeline connector: plated alloy steel; minimum 5,000 lb static strength with 3,600 lb gate strength
-
Anchorage connector: plated alloy steel; minimum 5,000 lb static strength with 3,600 lb gate strength
-
Static strength: 3,600 lb minimum
-
ANSI SRL Class/Type: Class 2 SRL
-
Average arrest force: 1,350 lb
-
Maximum arrest force: 1,800 lb
-
Maximum arrest distance: 42″
-
ANSI user capacity: 130 to 310 lb maximum
-
OSHA user capacity: 130 to 310 lb maximum
FAQs
Q: What scenarios justify using a “leading-edge” rated SRL like this one?
A: Use when the lifeline may travel over or be subjected to sharp or exposed edges, or when anchorage is below the dorsal D-ring, to ensure cut-resistance and appropriate deceleration.
Q: How does the load-indicating swivel snap hook benefit inspection and safety?
A: It provides a visual indication if a fall event has occurred, enabling removal from service and inspection before further use.
Q: What are the benefits of the external ViewPack® energy absorber cover?
A: It allows visual inspection of the absorber condition and places the absorber outside the main housing to preserve lifeline integrity after deployment.
Q: What should I check specifically on the cable lifeline before each use?
A: Inspect the galvanized cable for broken strands, kinks or corrosion; check the swivel hook for proper gate function and the housing for signs of damage or deformation.
