ALBION #360-1 1/10 Gallon Core Air-Powered Cartridge Gun

The Albion 360-1 Core Air-Powered Cartridge Gun is a professional 1/10-gallon (10 oz) pneumatic dispenser engineered for smooth, low-fatigue bead control. Its air valve provides instant on/off flow that reduces stringing, while an adjustable regulator on the line lets you match output to material viscosity and nozzle size. A swivel half-barrel carriage improves access around corners and detail work, and the rigid frame keeps the plunger aligned for clean starts, consistent bead size, and fast production with common construction sealants and adhesives.

Key Features:

• Pneumatic drive for smooth, low-effort dispensing of 10 oz cartridges

• Instant on/off air valve helps minimize stringing and ooze

• Swivel half-barrel carriage for better access and bead orientation

• Works with standard construction sealants and adhesives

• Lightweight, durable build for daily jobsite use

• Model/MPN: 360-1
• Line/Type: Core air-powered (pneumatic) cartridge gun
• Capacity: 1/10 gallon (10 oz / 300 mL) cartridges
• Drive: Pneumatic (requires regulated compressed air supply)
• Air Inlet: 1/4" NPT (use shop air hose with regulator/filter per site standards)
• Carriage: Swivel/rotating half-barrel
• Typical Pressure Range: Set at the line to suit material/nozzle (start low and adjust)
• Compatible Materials: Construction sealants/adhesives (per manufacturer guidance)
• Color/Finish: Green/Metal/Black
• Includes: (1) Albion 360-1 air-powered 10 oz cartridge gun (air hose/regulator and cartridges not included)

• Connect air: attach a clean, regulated air line (1/4" NPT) and set a low starting pressure.
• Prepare cartridge: cut the nozzle to size and pierce the inner seal.
• Load: open/rotate the half-barrel, seat the 10 oz cartridge, and close securely.
• Prime: pulse the trigger to build pressure until material reaches the tip; wipe the nozzle.
• Dispense: maintain a steady travel speed; fine-tune line pressure for bead size and material viscosity.
• Finish: shut off air, relieve pressure, and clean the nozzle and carriage before material cures.

Q: What size cartridges does the 360-1 accept?
A: Standard 1/10-gallon (10 oz / 300 mL) cartridges.

Q: What air supply do I need?
A: A clean, regulated compressed air source with a 1/4" NPT connection; start at a low pressure and adjust as needed.

Q: Does the gun have anti-drip?
A: The pneumatic valve provides instant start/stop; minimizing pressure and timing your release reduces ooze at the bead end.

Q: Can I adjust the flow rate?
A: Yes. Adjust the line regulator and select the appropriate nozzle opening to control output.

Q: What carriage style is used?
A: A swivel/rotating half-barrel carriage for easier positioning and visibility.
